A.W Faber, later Faber-Castell, was a German manufacturer of slide rules, starting in 1892, that began as A.W. Faber pencil factory as early as 1761. They are celebrating their 250th anniversary as of 2011. Slide rules started out as boxwood, with celluloid facings added in 1897. English manuals were translated by C.N. Pickworth for American distributor in Newark, New Jersey, USA. In 1905, the name was changed to Faber-Castell. Celluloid laminated mahogany was used from 1902 to 1912, followed by celluloid faced Pearwood. In 1952 all-plastic (Geroplast) versions were introduced. The duplex slide rules began in 1961. The most complex slide rule was the multi-colored Novo Duplex 2/83N. When electronic calculators first appeared, they tried manufacuring a hybrid slide rule with a four function calculator on the back side (the TR-1). When the TR-3 came out with scientific functions and the users stopped using the slide rule side, and the slide rule factories were shut down. The TR-4 was purely just a calculator in a slide rule shape. Faber-Castell still has factories in Germany and distribution houses in over most of the world.
More Faber-Castell history and timeline. See also Dating Pre-1920 Faber-Castell SlideRules by Trevor Catlow, UK.

Peter Holland has made an update of his extensive catalog of Faber-Castell Slide rules. It is very informative and can be used for identifying dates It's an 8MB PDF file.


A.W. Faber 44/87 Rietz (20inch/50cm)
L10

L10 A.W. Faber 44/87 Rietz (20inch/50cm)
Made in Germany - date code 53
Front Scale (Extended): 20inch // K, A [ B, CI, C ] D, L || 50cm
Back Scale: [ Sin Cos, Sin/tg, Tan Cot ] Back: Equivalents


Faber-Castell 4/22 Business Slide Rule (20 inch)
ISRM 13.10.09.04

Model number in well

Special adjustment tool supplied by manufacturer. 		Faber-Castell 4/22 Business Slide Rule (20inch)
Made in Germany - date code 53
Front Scale (Extended): 20inch // International conversion marks for weights and measures, DIF(P)(Int.) [ DIF(D), Val.(CI)C, C(P.P.)(D), ] D(S.P.)(Int.), L || sh/d, £
Back Scale: [ Exponential graduation for calculation of compound interest, C ]
Back: Instructions and Equivalents
Multiple hairlines, wrap-over cursor
Gift of Phillip Rodley, Upper Hutt, New Zealand

Note the small sheet-metal tool/screwdriver attached to the green sleeve in the image to the left. This was supplied with the slide rule so the user could loosen the cursor screws to calibrate the hairlines on the top and side and adjust the tension on the slide. These were easily lost because of their small size, and the first one acquired by ISRM.



Faber Castell 4/54 Darmstadt (50cm)
REF
Faber Castell 4/54 Darmstadt (50cm)
Made in Germany.
Front Scale (Extended): 50cm, L // K, A [ B, CI, C ] D, P || sin/cos, tg/ctg
Back Scale: [ LL1, LL2, LL3 ] Back: Equivalents
Archive - Courtesy of the Atsushi Tomozawa Collection, Japan


A.W.Faber Slide Rule C1892
REF 		A.W.Faber Slide Rule C1892
Made in Germany
Front Scale: 25cm // A [ B, C] D \\ 10in
Back Scale: Meter to inch conversion
Note: Cursor spring rides on angled bevel
Archive - Warren Burdine Collection


A.W. Faber Calculating Rule
REF S561 		A.W. Faber Calculating Rule - 1897-1906
Made in Germany (Bavaria) - English Text
Front Scale: 10in // A [ B, C] D || 26cm
Well: 27-52cm
Back Scale: [ S, L, T ]
Back: Conversions (English)
Original Owner: Millar
Note: Cursor spring rides on angled bevel


A.W. Faber Calculating Rule
REF S406 		A.W. Faber Calculating Rule 1897-1906
Made in Germany (Bavaria) - English Text
Front Scale: 10in // A [ B, C] D || 26cm
Well: 27-52cm
Back Scale: [ S, L, T ]
Back: Conversions (English)
Note: Cursor spring rides on angled bevel


A.W. Faber Calculating Rule
REF S342 		A.W. Faber Calculating Rule 1897-1906
Made in Germany (Bavaria) - English Text
Front Scale: 10in // A [ B, C] D || 26cm
Well: 27-52cm
Back Scale: [ S, L, T ]
Back: Conversions (English)
Note: Cursor spring rides on standardized square bevel




A.W.Faber 345 System Hohenner
ISRM 18.09.17.22 		A.W. Faber 345 System Hohenner
Made in Germany - Riveted Laminations, Railroad track scales
Front Scale: 10in // A [ B, C] D || 28cm
Back Scale: [ S, L, T ]
Back: Conversions (English)
Gift of Donald S. Bachelor Collection


A.W.Faber 349 System Hohenner
REF P194 		A.W. Faber 349 System Hohenner
Made in Germany
Front Scale: 14cm // A [ B, C] D || 15cm
Back Scale: [ S, L, T ]
Back: Conversions (German)


Faber-Castell 357
REF 		Faber-Castell 357 with Decimal Tracker
Made in Germany (Bavaria) - D.R. Patent 206408
Front Scale: 27cm // A [ B, C] D || 29cm
Well: 35-55cm
Back Scale: [ S, L, T ]
Back: Conversions (German)
Archive - Herman van Herwijnen's SR Catalog


A.W. Faber (357), Decimal Tracker
ISRM 15.09.27.03 		A.W. Faber (357) with Decimal Tracker (c1896-1899)
Made in Germany (Bavaria) - D.R. Patent 98350, 116832
Note: Railroad Track style divisions. pre-rivet celluloid (slide laminate has shrunk)
Front Scale: 27cm // A [ B, C] D || 29cm
Well: 35-55cm
Back Scale: [ S, L, T ]
Back: Conversions (unreadable)
Provided by the Tom Wyman Collection


Faber-Castell 360
REF S117 		Faber-Castell 360
Made in Germany (Bavaria) - D.R. Patent 206408
Front Scale: 27cm // A [ B, C] D || 28cm
Well: 35-55cm
Back Scale: [ S, L, T ]
Back: Conversions (German)
Original Owner/Location: Taken off German Soldier during WWII/DDR Germany


A.W. Faber "Castell" 360 (1903) (English)
ISRM 14.10.14.02 		A.W. Faber "Castell" 360 (English) dc3-3
Made in Germany (Bavaria) - D.R. Patent 206408
Front Scale: 10in // A [ B, C] D || 28cm
Back Scale: [ S, L, T ]
Back: Conversions (English)
Original Owner/Location: England


A.W. Faber "Castell" 360 (English)
REF S329 		A.W. Faber "Castell" 360
Made in Germany (Bavaria) - D.R. Patent 206408
Front Scale - Extended
10in // A [ B, C] D || 29.5cm
Back Scale: [ S, L, T ]
Back: Conversions (English)
Original Owner/Location: England. Initials on stock:HGM


Faber-Castell 361 (English)
REF S526 		Faber-Castell 361
Made in Germany (Bavaria)  - D.R.P. (Patent Pending)
Front Scale - Extended
10in // A [ B, C] D || 29.5cm
Back Scale: Blank
Back: Conversions (English)
Original Owner/Location: England


A.W. Faber 363 Mannheim (1909-1912)
ISRM 20.02.09.01
 A.W. Faber 363 Mannheim
Made in Bavaria. Note 'Railroad track' style divisions
Front Scale(extended): 10 inch // A [ B , C ] D \\ 28 cm
Well: 28-56cm
Back Slide: [ S, L, T ]
Back: Conversions (English)
Original Owner J.H.Broadhead.
Gift of Ruth Stanier of Hereford, UK.


A.W. Faber 367 Mannheim (1909-1912)
ISRM 16.07.01.01
 A.W. Faber 367 Mannheim
Made in Bavaria. Note 'Railroad track' style divisions
Front Scale(extended): 10 inch // A [ B , C ] D \\ 28 cm
Well: 28-56cm
Back Slide: [ S, L, T ]
Cursor: Decimal Keeper (missing lens)
Back: Conversions (English) faded
Original Owner Unknown
Gift of Phillip Rodley of Upper Hutt, New Zealand


A.W. Faber 368 Elektro (1909-1912)
ISRM 13.11.05.04 		A.W. Faber 368 Elektro - Version 2
Made in Bavaria. Note 'Railroad track' style divisions
Front Scale(extended): 27cm // A (KW) [ B (mm2)(HP), CI, C (Watt) ] D, \\ LL03, LL2
Well: Dynamo, Motor TL=%, Volt
Back Slide: Metal edge cursor for well [ S, L, T ]
Cursor: Metal tab for edge scales.
Back: Conversions (English)
Original Owner (marked on case): Doug Hamilton, New Zealand.
Gift of Phillip Rodley of Upper Hutt, New Zealand


A.W. Faber "Castell" 369 (1933)
ISRM 20.04.01.075 		A.W. Faber "Castell" 369 dc3-33 (March 1933)
Made in Germany (Bavaria) - D.R.P.206428
Front Scale - Extended
5in // A [ B, C] D || 14cm
Back Scale: [ S, L, T ]
Back: Conversions (English)
Gift of the Philip Stanley Collection


A.W. Faber 374 System Pickworth
REF 		A.W. Faber 374 System Pickworth
Made in Germany (Bavaria) - Designed by C.N. Pickworth, Wh. Sc., England
Front Scale: 27cm // A [ B, C] D || 29cm
Back Scale: [ S, L, T ]
Back Window Scale: K [ L ]
Archive - Herman van Herwijnen's SR Catalog


A.W. Faber "Castell" 375 System Rietz (c1929)
ISRM 14.05.01.02

Instructions for Model 361 which came with this model 375 slide rule. (4.90MB PDF). It is in very poor condition and is missing 1/3 of one page.

A.W. Faber "Castell" 375 System Rietz
Made in Bavaria - D.R. Patent 206408
Note: Railroad Track style divisions, riveted laminations
Front Scale: 10in // K, A [ B, C1, C ] D, L || 29cm
Back Slide: [ cos, sin/tg, ctg ]
Back: Conversions (English)
Original Owner: .J.H.N. Haigh (marked on slide rule, case and manual) presumably of New Zealand.
Gift of Phillip Rodley, New Zealand



A.W. Faber "Castell" 378 Electro (c1929)
ISRM 14.01.03.01 		A.W. Faber "Castell" 378 Electro
Made in Bavaria - D.R. Patent 206408
Note: Railroad Track style divisions, riveted laminations
Front Scale: 27cm // LL2, A (Kw) [ B (mm2)(H.P.), C (Watt) ] D, LL03 || Log (Note:25.4cm long)
Well: Motor TL=%, Volt
Back Slide: [ S, L, T ]
Back: Conversions (English)
Gift of Phillip Rodley, Upperhutt, New Zealand
Faber-Castell 378 Instructions (c1929) Slide Rule Instructions (Spanish ) 2.56MB. Scan By José G Fernández, Spain. Courtesy of reglasdecalculo.com


A.W. Faber "Castell" 379 Electro (c1920)
ISRM 20.04.10.072 		A.W. Faber "Castell" 379 Electro
Made in Germany - D.R. Patent 206408
Note: Railroad Track style divisions, riveted laminations
Front Scale: 14cm // LL2, A (Kw) [ B (mm2)(H.P.), C (Watt) ] D, LL03 || Log (Note:12.7cm long scale)
Well: Motor TL=%, Volt
Back Slide: [ S, L, T ]
Back: Conversions
Gifted by the Philip Stanley Collection



A Specimen with Faber cursor
A.W. Faber "Castell" 379 Electro (c1920)
ISRM 13.10.07.02 		A.W. Faber "Castell" 379 Electro (Date Code 0)
Made in Germany - D.R. Patent 206408
Note: Railroad Track style divisions, riveted laminations. Dietzgen cursor.
Front Scale: 14cm // LL2, A (Kw) [ B (mm2)(H.P.), C (Watt) ] D, LL03 || Log (Note:12.7cm long scale)
Well: Motor TL=%, Volt
Back Slide: [ S, L, T ]
Back: Conversions
Original Owner: Dr. Lee J. W. Levent, Hell Gate Power Station, (Marked on Back of stock) in South Bronx, New York.
Archive Scan with cursor (green background) Jorge Fabregas collection, Spain - reglasdecalculo.com
Historical Note: The Hell Gate Power Station, where this slide rule was used, was built in Bronx, New York in 1921, by Thomas E. Murray (1860-1929) of the United Electric Light & Power Company and later operated by Consolodated Edison. It was closed in 1973. It assumed the owner of the above slide rule, Dr. Lee J. W. Levent, was one of the many engineers on the project. The title Dr., in this case, being a Ph.D in electrical engineering. Thomas E. Murray was responsible for the design and construction of nine power stations in New York City, most of which continued to operate well into the second half of the 20th century.Murray built three stations in the city during the 1920s, each among the largest ever constructed anywhere. The first, Hell Gate, was undertaken by United to supplement Sherman Creek and supply the northern suburbs and Queens. Named for the mariner's term for the treacherous currents where the East River meets Long Island Sound, Hell Gate opened in November 1921. Planned for a capacity of 280 MW, so rapid was the advance in component design that it was actually rated at 605 MW to make it the world's most powerful steam electric station upon installation of the last unit in 1928. Hell Gate introduced Murray's most significant nonelectrical innovation for power stations: the water-cooled steel furnace wall to replace the fire brick refractory furnace wall used previously. The steel wall was comparatively thin, which afforded a substantial increase in furnace capacity and a major reduction in maintenance expense. This Murray innovation became the industry standard after the successful test at Hell Gate.


Faber-Castell 389 10cm (1939)
ISRM 20.04.01.258 		Faber-Castell 389 10cm
Made in Germany
Front Scale: 10cm // A [ B, C ] D || 12.3cm
Back Scale: [ S, L, T
Back Stamped: Pablo Ferrando Montevideo
Gift of Phillip Stanley Collectio


Faber-Castell 398 Electro (all glass cursor)
ISRM 11.12.17.01 		Faber-Castell 398 Electro
Made in Germany
Front Scale(extended): 27cm // LL2, A (KW) [ B (PS), CI, C (Watt) ] D, LL03 || LL
Well: Dynamo, Motor TL=%, Volt
Back Slide: [ S, L, T ]
Cursor: Multiple Hairlines: W, PS/q, d
Back: Blank
Original Owner (marked on back of stock): Robert Kaoga


S441 Faber-Castell 398 Electro (Metal framed cursor) 		Faber-Castell 398 Electro
Made in Germany for Australian Market
Front Scale (extended)
10in // LL2, A (Kw) [ B (H.P.), deg rise, CI, C (Watt) ] D, LL03 || LL
Well: Dynamo, Motor TL=%, Volt
Back Slide: [ S, L, T ]
Back: Conversions (English)
Original Owner/Location: W.F. Backhouse/Australia


Faber-Castell 1/22 Business Slide Rule (1959)
ISRM 14.07.22.06 		Faber-Castell 1/22 Business Slide Rule dc 11-59
Made in Germany
Front Scale (extended)
10in // Conversion, DF(KZ) [ CF, CI (p%), C(T) ] D(Z), L || sh/d, Pounds Sterling
Back Slide: [ LL1, LL2, %, C ]
Channel: CM scale Cursor: 3 hairlines
Back: Instructions, Conversions, Parities.
Gift of Phillip Rodley, Upperhutt, New Zealand


Faber-Castell 111/22 Disponent
S056 		Faber-Castell 111/22 Disponent
Made in Germany
Front Scale (extended)
27cm // Conversion, DF(KZ) [ CF, CI (p%), C(T) ] D(Z), L, sh/d, Pounds Sterling
Back Slide: [ LL1, LL2, %, C ]
Channel: CM scale Cursor: 3 hairlines
Back: Blank


Faber-Castell 111/22 Disponent
ISRM 20.01.03.03 		Faber-Castell 111/22 Disponent
Made in Germany
Front Scale (extended)
27cm // Conversion, DF(KZ) [ CF, CI (p%), C(T) ] D(Z), L, sh/d, Pounds Sterling
Back Slide: [ LL1, LL2, %, C ]
Channel: CM scale Cursor: 3 hairlines
Back: Instructions (German)
Gift of Rachel Katzer of Starkville, Mississippi


Faber-Castell 1/28 Super-Business
ISRM 14.05.01.03 		Faber-Castell 1/28 Super-Business - dc11-07
Made in Germany
Front Scale (extended)
27cm, L // K, DF(P/Int) [ CF(Days), CI(R%), C(Days) ] D(Int), A || sin/cos, tg/ctg
Back Slide: [ LL1, LL2, C ]
Cursor: 4 hairlines
Back: Monetary Conversion tables, Units conversions.
Gift of Phillip Rodley, Upperhutt, New Zealand

Instructions (791KB PDF) and Plastic case with clamshell lid.


Faber-Castell 111-48 System Dr. Winkel
REF S307 		Faber-Castell 111-48 System Dr. Winkel
Made in Germany
Front Scale (machining speeds and feeds)
Back: Reference Tables
Archive - Jim Cerny Collection See another at Hubert van Dongen (Netherland) Collection an ISRM associate.



Faber-Castell 1/54 Darmstadt (Import) V1
REF S037 		Faber-Castell 1/54 Darmstadt (Import) V1
Made in Nürnberg, Germany
Front Scale (extended)
27cm, lg // K, A [ B, CI, C ] D, P || sin/cos, tg/ctg
Back Slide: [ LL1, LL2, LL3 ]
Note: Compare back of slide with the Aug 1970 1/54 below. It has the [ LL1, LL2, LL3 ] scales.
Well (Channel): Centemeter scale 33.2 to 56.8cm
Note: The stock is 30cm long. When you extend the slide, the reading of the left edge of the slide on the inch scale in the well gives the overall length of the stock and slide.
Cursor: 3 hairlines
Back: Instruction (Swedish) label dcK8sv, "Import" stamp on stock.
Original Owner/Location: M. Bergfors



Faber-Castell 1/54 Darmstadt (Aug 1970) V2
ISRM 13.12.03.03 		Faber-Castell 1/54 Darmstadt dc870-54 V2
Made in Nürnberg, Germany
Front Scale (extended)
27cm, lg // K, A [ B, CI, C ] D, P || sin/cos, tg/ctg
Back Slide: [ LL1, LL2, LL3 ]
Note: Compare back of slide with the Import 1/54 above. It has the [ CF, CIF, C ] scales.
Well (Channel): Centemeter scale 33.2 to 56.8cm
Note: The stock is 30cm long. When you extend the slide, the reading of the left edge of the slide on the inch scale in the well gives the overall length of the stock and slide.
Cursor: 3 hairlines
Back: Instruction (German) label dcK8d


Faber-Castell 1/54A Darmstadt with Addiator
ISRM 13.08.12.07 		Faber-Castell 1/54A Darmstadt with Addiator
Made in Germany
Front Scale (extended)
27cm, lg // K, A [ B, CI, C ] D, P || sin/cos, tg/ctg
Back Slide: [ LL1, LL2, LL3 ]
Well (Channel): Inch scale 12 to 22-5/8 inches
Note: The stock is 12" long. When you extend the slide, the reading of the left edge of the slide on the inch scale in the well gives the overall length of the stock and slide.
Cursor (wrap around edges): 7 hairlines/gauge marks A-B Scales: s, kW, HP. C-D Scales: kW, s, HP. Lg, sin, tg scales
Back: Mechanical Addiator for addition and subtraction. Instructions.
Note: The Stylus for the Addiator is mounted in a bored hole at the left end of the stock.
Original Owner/Location: J.W. Hand of Christchurch, New Zealand.
Gift of Phillip Rodley, Upper Hutt, New Zealand.


Faber-Castell 111/54 Darmstadt (1953) No scale labels
ISRM 23.05.18.01
Clamshell case with locking pins. 		Faber-Castell 111/54 Darmstadt dc753 1953
Made in Germany
Front Scale (extended)
27cm // K, A [ B, CI, C ] D, P, S, T || lgX
Back Scale: [LL1, LL2, LL3]
Multiple hairlines PS, KW, q, d
Back: Calculation examples.
Gift of Terry L. Kirkpatrick of Safety Harbor, Florida.


Faber-Castell 111/54 Darmstadt (early)
ISRM 23.07.18.09 		Faber-Castell 111/54 Darmstadt
Made in Germany
Front Scale (extended)
27cm // K, A [ B, CI, C ] D, P, S, T || lgX
Back Scale: [LL1, LL2, LL3]
Multiple hairlines PS, KW, q, d
Gift of John Pazereskis of Galesburg, Illinois.


Faber-Castell 111/54 Darmstadt
S162 		Faber-Castell 111/54 Darmstadt
Made in Germany
Front Scale (extended)
27cm // K, A [ B, CI, C ] D, P, Sin Cos, Tan Ctg || lgX
Back Scale: [ LL1, LL2, LL3 ]
Multiple hairlines PS, KW, q, d
Original Owner/Location: Unk/Hungary


Faber-Castell 111/54A Darmstadt with Addiator
ISRM 18.07.26.05

 Faber-Castell 111/54A Darmstadt with Addiator
Made in Germany
Front Scale (extended)
10in // K, A [ B, CI, C ] D, P, Sin Cos, Tan Ctg || lgX
Back Scale: [ LL1, LL2, LL3 ]
Multiple hairlines PS, KW, q, d
Cursor (wrap around edges): 7 hairlines/gauge marks A-B Scales: s, kW, HP. C-D Scales: kW, s, HP. Lg, sin, tg scales
Back: Mechanical Addiator for addition and subtraction. Instructions.
Note: The Stylus for the Addiator is mounted in the sleeve.
Gifted by William (Bill) Boas of Wray, Colorado.

 William (Bill) Augustus Boas, is an independent journalist and writer. Bill grew up in the Bronz, New York and served in the U.S. Navy from 1962 to 1966, on ships with the 2nd and 6th Fleets, and under Commander, Fleet Air Mediterranean at Naples, Italy. He worked as the Business Administrator of the American Academy of Dramatics Arts in 1968, and a press aide for a W. Averell Harriman political cause in 1969. He has been a correspondent for The Wall Street Journal, Business Week magazine, and United Press International as well as numerous regional general interest and trade periodicals. For his writing, he received an Honorary Citizenship of the State of Texas from Governor Price Daniel in 1961; a George Washington Honor Medal from the Freedom's Foundation at Valley Forge in 1964; and the 1982 Morton Margolin Prize for Distinguished Business Reporting from the Morton Margolin Trust administered by the College of Business Administration of the University of Denver. One of his interests was collecting slide rules, . He now lives in Wray, Colorado engaged in other writing and photography projects
1/54A, 111/54A Manual 4.2MB PDF


Faber-Castell 1/60/360 Mannheim (Sep 1937)
ISRM 13.09.16.01 		Faber-Castell 1/60/360 Mannheim dc37-10
Made in Germany
Front Scale (extended)
10inch // A [ B, CI, C ] D || 30cm
Back Scale: [sin cos, lg, tg ]
Well: 33-60cm Scale: Note: The stock is 30cm long. When you extend the slide, the reading of the left edge of the slide on the inch scale in the well gives the overall length of the stock and slide.
Back: Equivalents (English)
Original Owner/Location: Unk/England


Faber-Castell 1/60 Mannheim
REF S429 		Faber-Castell 1/60 Mannheim
Made in Germany
Front Scale (extended)
27cm // A [ B, CI, C ] D || 1:25 mm
Back Scale: [sin cos, lg, tg ctg ]
Well: 33-60cm scale
Note: The stock is 30cm long. When you extend the slide, the reading of the left edge of the slide on the inch scale in the well gives the overall length of the stock and slide.
Back: Equivalents (German)
Original Owner/Location: Unk/England


Faber-Castell 1/60 Mannheim (1940)
ISRM 14.07.02.32 		Faber-Castell 1/60 Mannheim
Made in Germany - Date code June 1950. Railroad Track Scales. Metal framed cursor.
Front Scale (extended)
27cm // A [ B, CI, C ] D || 1:25 mm
Back Scale: [sin cos, lg, tg ctg ]
Well: 33-60cm scale
Note: The stock is 30cm long. When you extend the slide, the reading of the left edge of the slide on the inch scale in the well gives the overall length of the stock and slide.
Back: Equivalents (German)
Original Owner/Location: Unk/England


Faber-Castell 1/60 Mannheim (1950)
ISRM 20.12.04.01
 Faber-Castell 1/60 Mannheim
Made in Germany - Date code August 1950.RR Track Scales. All plastic cursor.
Front Scale (extended)
10in // A [ B, CI, C ] D || 30cm
Back Scale: [sin cos, lg, tg ctg ]
Well: 33-60cm scale
Note: The stock is 30cm long. Extending the slide, the reading of the left edge of the slide on the cm scale in the well allows up to a 60cm measurement.
Back: Equivalents (paper label in English)
Original Owner: Peter John Halsey of England
Gift Of Neil Halsey, son of Peter J. Halsey, UK
Peter John Halsey was born in Barnet ,Hertfordshire in the United Kingdom in 1934. This Faber Castell Slide Rule 1/60 was bought for him by his parents when he was studying Building at Watford Technical College. On leaving school he joined the Tentest Company, the British branch of the Canadian Tentest Fibre Board Company. After completing his National Service in the Army, he worked as a surveyor and draughtsman for Matthew Hall air conditioning, and Andrews air Conditioning for a few years. He returned to the Tentest Company to sell their Ventilating Ceiling Systems. He then joined Hunter Melsom Ceilings as a Director, where I stayed until his retirement in 2001


A.W. Faber 1/60 Mannheim (1950)
ISRM 17.05.02.49 		A.W. Faber 1/60 Mannheim
Made in Germany - Date code 750 (July 1950). Railroad Track Scales
Front Scale (extended)
10in // A [ B, CI, C ] D || 30cm
Back Scale: [sin cos, lg, tg ctg
Note: The stock is 30cm long. When you extend the slide, the reading of the left edge of the slide on the inch scale in the well gives the overall length of the stock and slide.
Back: Equivalents (English)
Gift Of Mike Weaver, UK


A.W. Faber Castell 1/61/361 Mannheim (1938)
REF 		A.W. Faber Castell 1/61/361 Mannheim
Made in Bavaria - Date code 750 (1938). Railroad Track Scales
Front Scale (extended)
10in // A [ B, CI, C ] D || 30cm
Back Scale: Blank ]
Well: Blank
Back: Equivalents (English)
Scan from Jorge Fabregas Zazza Collection at Reglasdecalculo.com


Faber-Castell 111/66 Demegraph System Schirmer
ISRM 14.07.22.04 		Faber-Castell 111/66 Demegraph System Schirmer Typesetters Rule
Made in Germany - One piece plastic cursor
Front Scale (extended)
10in // differentials (yards), DF(P/Int) [ CF(Days), CI(R%), C(Days) ] D(Int), Area, Yards 1, Yards 2, Yards 3
Back Slide: [ LL1, LL2, C ]
Cursor: 5 hairlines
Back: 0-42, Pica font sizes 1-128, 0-42
Gift Of Phillip Rodley, Upperhutt, New Zealand


A.W. Faber "Castell" 1/75/375 System Rietz 1939
ISRM 21.12.01.03 		A.W. Faber "Castell" 1/75/375 System Rietz - dc 39-2 (Feb 1939)
Made in Germany - aluminum cursor guide pinned to lens, Railroad Track style scale divisions.
Front Scale (extended) scales labeled
27cm // K, A [ B, C ] D, L || 1:25 0-7in
Back Slide: [ Sin Cos, Sin/Tg, Tg Ctg ]
Well: 33cm to 60cm
Cursor: 5 hairlines: HP, KW, PS, d, s.
Back: Conversions (German)
Original Owner: Kuchenbuch August Hildesheim, Leunissh.26
Gift Of Andreas Poschinger of Munich, Germany


Faber-Castell 1/87 Rietz
REF S169 		Faber-Castell 1/87 Rietz
Made in Germany - metal framed cursor
Front Scale (extended)
27cm // K, A [ B, CI, C ] D, L
Back Slide: [ cos, sin/tg, ctg ]
Cursor: 3 hairlines
Back: Conversions (English)
Original Owner/Location: M. Bergfors/Germany


Faber-Castell 1/87/387 System Rietz
ISRM 20.05.23.01 		Faber-Castell 1/87/387 System Rietz
Made in Germany - RR Track scales Missing aluminum cursor
Front Scale (extended)
27cm // K, A [ B, C1, C ] D, L || 1:25
Back Slide: [ cos, sin/tg, ctg ]
Cursor: Missing
Well: 33-60cm
Back: Conversions (German)
Gift of Joe Blatt of California..


A.W. Faber "Castell" 1/87 System Rietz 1943
ISRM 13.02.01.01 		A.W. Faber "Castell" 1/87 System Rietz - dc 43-8 (Aug 1943)
Made in Germany - metal edged cursor
Front Scale (extended) scales labeled
27cm // K, A [ B, CI, C ] D, L || 1:25 0-7in
Back Slide: [ Sin Cos, Sin/Tg, Tg Ctg ]
Cursor: 5 hairlines: HP, KW, PS, d, s. Labels stamped in sheetmetal.
Back: Conversions (German)
Original Owner: Frank Woodin Barnett (1889 - 1958)
Donated by Raymond DuBois of Camas, Washington.

Frank Barnett 		Raymond DuBois, the grandson of Frank Barnett, writes: "This slide rule belonged to my grandfather. He joined the faculty at Piedmont High School in Piedmont, California in 1922 and conducted classes in mechanical drawing, manual training and wood and print shop instruction. He retired in 1956 and died in 1958 of leukemia."


A.W. Faber "Castell" 1/87 System Rietz 1944
ISRM 21.12.01.02 		A.W. Faber "Castell" 1/87 System Rietz - dc 43-5 (May 1944)
Made in Germany - aluminum cursor guide pinned to lens, Railroad Track style scale divisions.
Front Scale (extended) scales labeled
27cm // K, A [ B, CI, C ] D, L || 1:25 0-7in
Back Slide: [ Sin Cos, Sin/Tg, Tg Ctg ]
Cursor: 5 hairlines: HP, KW, PS, d, s.
Back: Conversions (German)
Original Owner: Kuchenbuch August Hildesheim, Leunissh.26
Gift Of Andreas Poschinger of Munich, Germany


Faber-Castell 1/87 System Rietz
REF S505 		Faber-Castell 1/87 System Rietz
Made in Germany - aluminum cursor guide pinned to lens
Front Scale (extended)
27cm // K, A [ B, C1, C ] D, L
Back Slide: [ cos, sin/tg, ctg ]
Cursor: 3 hairlines
Well: 33-60cm (used with tab on slide)
Back: Conversions (German)


Faber-Castell 1/87 SystemRietz (1950)
ISRM 17.10.10.06 		Faber-Castell 1/87 System Rietz, dc50
Made in Germany - All plastic cursor
Front Scale (extended): 10inch // K, A [ B, CI, C ] D, L ||30cm
Back Slide: [ sin cos, sin/tg, tg ctg ]
Well: 33-60cm (used with tab on slide)
Cursor: Plastic - 3 hairlines
Back: Conversions (English)
Original Owner/Location: Brian C. Cunningham, Australia (has name on back of stock)
Donated by Andrew (son) and Barbara (wife) Cunningham, Willagee, W.A., Australia.

Brian C. Cunningham (1935-2013) 		Brian was born in Port Pine, South Australia, Australia. His education commenced there and continued at the South Australian School of Mines where he gained his Diploma in Mining & Metallurgy. He became a Student Member of the Australian Institute of Mining & Metallurgy rising to a Fellow member. Brian started his career as a Metallurgical Cadet at the B.H.A.S. (Broken Hill Associated Smelters) in Port Pirie. He transferred to Hamersley Iron in Perth, Western Australia, the subsidiary company of Conzinc Rio Tinto Aus. where he became an Executive Officer of the Hamersley Iron Group. In Brian's studies and work his slide rules where used extensively. This specimen was made when Brian was 15 years old.


Faber-Castell 1/87 System Rietz (1954)
ISRM 14.07.22.05 		Faber-Castell 1/87 System Rietz dc5-54
Made in Germany - all plastic cursor, Castell on slide. Rail road Track Style Divisions.
Front Scale (extended) scales labeled
10inch // K, A [ B, CI, C ] D, L || 30cm
Back Slide: [ S Cos, ST, T Ctg ]
Well: 13 inch to 24 inch.
Cursor: 5 hairlines: HP, KW, PS, d, s
Back: Conversions (English) Note: gummed label
Gift of Phillip Rodley, Upper Hutt, New Zealand


A.W. Faber 1/87 System Rietz (1958)
ISRM 20.08.15.07 		A.W. Faber 1/87 System Rietz (1958)
Made in Germany - dc562 (Feb 1958). all plastic cursor, Castell on slide
Front Scale (extended) No scale labels
10inch // K, A [ B, CI, C ] D, L || 30cm
Back Slide: [ sin Cos, sin/tg, tg Ctg ]
Cursor: 5 hairlines: HP, KW, PS, d, s
Back: Conversions (English) Printed on plastic laminate.
Gift of Robert Carlisle


A.W. Faber 1/87 SystemRietz (1962)
ISRM 17.05.02.14 		A.W. Faber 1/87 System Rietz (1962)
Made in Germany - dc562 (May 1962). all plastic cursor, Castell on slide
Front Scale (extended) scales labeled
10inch // K, A [ B, CI, C ] D, L || 30cm
Back Slide: [ S Cos, ST, T Ctg ]
Cursor: 5 hairlines: HP, KW, PS, d, s
Back: Conversions (English) Printed on plastic laminate.
Gift of Mike Weaver, UK


Faber-Castell 1/87A Sys. Rietz with Addiator
ISRM 14.05.01.01 		Faber-Castell 1/87A System Rietz with Addiator
Made in Germany - all plastic cursor
Front Scale (extended) scales labeled
10inch // K, A [ B, CI, C ] D, L || 30cm
Back Slide: [ S Cos, ST, T Ctg ]
Cursor: 5 hairlines: HP, KW, PS, d, s
Back: Addiator with scribe tool, Conversions (English)
Gift of Phillip Rodley, Upper Hutt, New Zealand
Instructions (11.3MB pdf)


Faber-Castell 11/87 System Rietz (1945)
ISRM 22.05.06.14 		Faber-Castell 11/87 System Rietz RR Track Scales
Made in Germany - (Dec 1945) all plastic cursor,
Front Scale (extended) scales labeled
27cm // K, A [ B, CI, C ] D, L
Back Slide: [ S Cos, ST, T Ctg ]
Cursor: 5 hairlines: HP, KW, PS, d, s
Back: Conversions (Germany) .
Gift of Nancy Ulrich for the Ted Ulrich Collection


Faber-Castell 111/87 System Rietz dc467
ISRM 18.04.06.07 		Faber-Castell 111/87 System Rietz dc467
Made in Germany - (Apr 1967) all plastic cursor, Castell on slide
Front Scale (extended) scales labeled
27cm // K, A [ B, CI, C ] D, L
Back Slide: [ S Cos, ST, T Ctg ]
Cursor: 5 hairlines: HP, KW, PS, d, s
Back: Conversions (Germany) Note: Printed on stock.
Gift of the Leroy Hausler Collection


Faber-Castell 111/87A Sys. Rietz with Addiator
ISRM 22.06.01.01 		Faber-Castell 111/87A System Rietz with Addiator dc1069
Made in Germany - all plastic cursor. Thin plastic stock
Front Scale (extended) scales labeled
10inch // K, A [ B, CI, C ] D, L
Back Slide: [ S Cos, ST, T Ctg ]
Cursor: 5 hairlines: HP, KW, PS, d, s
Back: Addiator requiring scribe tool to move and clear enties. Conversions (English)
Gift of Ron Gribnitz of South Africa


Faber-Castell 1/92 Log Log
ISRM 22.06.01.02 		Faber-Castell 1/92 Log Log dc168
Made in Germany - all plastic cursor. wood stock. RR track scales
Front Scale (extended) scales labeled
10inch // LL2, A [ B, CI, C ] D, LL3 || K
Back Slide: [ S Cos, ST, T Ctg ]
Cursor: 5 hairlines: HP, KW, PS, d, s
Gift of Ron Gribnitz of South Africa


Faber-Castell 1/94/394 (Joe Klawun No.25) Sys.Rietz (Dec 1938)
ISRM 13.09.16.03 		Faber-Castell 1/94/394 (Joe Klawun No.25) Sys.Rietz dc38-12
Made in Germany for Feinmessinstitut Joe Klawun, Berlin - Charlottenburg 5
Note: "Railroad track" style division
Front Scale (extended) scales labeled
27cm // K, A [ B, CI, C ] D, L || 10inch
Back Slide: [ S Cos, ST, T Ctg ]
Cursor: Metal framed
Back: Conversions (German)
Original Owner: Spordeler (on back of stock)


Faber-Castell 1/98 Elektro
S172 		Faber-Castell 1/98 Elektro
Made in Germany - Rail Road Track style scales
Front Scale (extended)
27cm // LL2, A(kw) [ B, CI, C ] D, LL3 || L
Back Slide: [ sin cos, lg, tg ctg ]
Well: Dynamo, Efficiency, Volt
Note: the metal edge on the left end of the slide is used to transfer the readings from the scales in the well.
Cursor: Multiple hairlines: PS, KW
Back: Conversions (German)
Original Owner/Location: Hartmut A. Niemann/Germany


Faber-Castell 1/98 Elektro
ISRM 18.04.06.82 		Faber-Castell 1/98 Elektro
Made in Germany
Front Scale (extended): 10in // LL2, A(kw) [ B, Temperature, CI, C ] D, LL3 || L
Back Slide: [ sin cos, lg, tg ctg ]
Well: Dynamo, Efficiency, Volt
Note: the metal edge on the left end of the slide is used to transfer the readings from the scales in the well.
Cursor: Multiple hairlines: PS, KW
Back: Conversions (English)
Gift of the Leroy Hausler Collection
Images needed
Faber-Castell 111/98 Elektro
REF 		Faber-Castell 111/98 Elektro
Made in Germany
Front Scale (extended)
10inch // LL2, A(kw) [ B, CI, C ] D, LL3, W, V, K
Back Slide: [ sin cos, lg, tg ctg ]
Cursor: Multiple hairlines: PS, KW
Back: Properties,Formulae/Conversions:Maths;Mech;Elect;Civil Eng;Physics.


Faber-Castell 1/98/398 Elektro (1937)
REF S290 		Faber-Castell 1/98/398 Elektro dc37
Made in Birnbaum,Germany by A.W. Faber
Material: Celluloid laminated Pearwood
Front Scale (extended)
10in // LL2, A(kw) [ B(hp), Temp°, C1, C ] D, LL3 || K
Back Slide: [ sin/cos, lg, tg ]
Well: Efficiency, Volt
Cursor: 3 hairlines: W, Hp, d, metal wrapped and divided with hairline for bottom 'K' Scale: Back: Conversions (English)
Original Owner/Location: N.T. Chen/Hong Kong, China

Note: First two characters mean "Germany" the last "Made In"


Faber-Castell 1/98/398 Elektro (1938)
ISRM 13.12.07.01 		Faber-Castell 1/98/398 Elektro dc38-4
Made in Birnbaum,Germany by A.W. Faber
Material: Celluloid laminated Pearwood
Front Scale (extended)
10in // LL2, A(kw) [ B(hp), Temp°, C1, C ] D, LL3 || K
Back Slide: [ sin/cos, lg, tg ]
Well: Efficiency, Volt
Cursor: 3 hairlines: W, Hp, d, metal wrapped and divided with hairline for bottom 'K' Scale: Back: Conversions (English)
Original Owner: W. Craick (marked on stock). This specimen was obtained in Adelaid, Australia.


Faber-Castell 1/98/398 Elektro (1939)
ISRM 19.12.14.01 		Faber-Castell 1/98/398 Elektro dc39-4
Made in Birnbaum,Germany by A.W. Faber
Material: Celluloid laminated Pearwood
Front Scale (extended)
10in // LL2, A(kw) [ B(hp), Temp°, C1, C ] D, LL3 || K
Back Slide: [ sin/cos, lg, tg ]
Well: Efficiency, Volt
Cursor: 3 hairlines: W, Hp, d, metal wrapped and divided with hairline for bottom 'K' Scale: Back: Conversions (German)
Gift of Diana Schmidt of Cedarville, California.


Faber-Castell 2/82 Duplex
ISRM 11.10.26.01.X 		Faber-Castell 2/82 Duplex (dc 1157)
Made in Germany - 24 scales
Front Scale: Cot1 T1, T2 Cot2, A [ B, BI, CI, C ] D, P, S Cos P
Back Scale: LL03, LL02, LL01, K [ K', L, ST, CF ] DF, LL1, LL2, LL3
Multiple hairlines: 360, d, A, KW, PS
Original Owner: Roman Marian Russek (1933-2011)
Donated by Shiela Russek, Toronto, Canada, wife or Roman Russek. Photo provided by daughter Irene Casey (nee Russek).
Roman Marian Russek (1933-2011)was known for his wide knowledge of power cables and, in later years, for his expertise the transfer of technology within international joint ventures. At the close of WWII Roman was a member of the Polish Army under British command. With Communism descending on his homeland his left to study in Britain where he earned engineering degrees from Heriot Watt University (Edinburgh) and London University. By 1949 he was a Scientific Officer in the Wood Lane Research Laboratories of British Insulated Callenders Cables in London. There he was assigned to teams studying the mechanical behavior of aluminum sheaths, electrical characteristics of oil impregnated paper as well as assisting in the development of flexible joints for submarine cables destined to be used in the HVDC link between North and South Island in New Zealand. As Design Engineer and then Department Manager Roman traveled widely within Canada and internationally representing CWC in many negotiations and discussions with customers and associated firms. He was fluent in five languages. Later as Vice-President Technical Services Roman spent another 14 years transferring technology from the domestic company to the many fledgling associate companies in Mexico, Colombia, Venezuela, Dominican Republic, Ireland, Spain, Brazil. South Africa, Nigeria, New Zealand, Australia and Iran. Roman and his wife Shiela spent much of their retirement years traveling around the world. Read this An article about Roman Russek by his friend XAVIER KATAQUAPIT


Faber-Castell 2/82 Duplex
ISRM 12.06.24.01 		Faber-Castell 2/82 Duplex
Made in Germany - 24 scales
Front Scale: L, T1, T2, A [ B, BI, CI, C ] D, ST, S, P
Back Scale: LL03, LL02, LL01, K [ K', C, CIF, CF ] DF, LL1, LL2, LL3
Multiple hairlines: 360, d, A, KW, PS

Mr. Huang 		Donated by the Huang Collection.
The collector, who prefers to remain anonymous, obtained a B.S. degree in Physics from Taiwan's National Tsing Hua University in 1971. His love for computation has encouraged him to build a collection of slide rules, HP and TI calculators, as well as abaci, many displayed at ISRM.


Faber-Castell 2/82 Duplex Variation 2 scales
ISRM 22.07.06.49.X 		Faber-Castell 2/82 Duplex Variation 2 scale set
Made in Germany - 27 scales
Front Scale: 25cm, T1 Cot, T2Cot, A [ B, BI, CI, C ] D, P, S Cos, 10inch
Back Scale: LL03, LL02, LL01, K [ K', L, ST, CF, ] DF, LL1, LL2, LL3
Multiple hairlines: 360, d, A, KW, PS
Gift of Cindy Tate, Bozeman, Montana.


Faber-Castell 2/82N Duplex
ISRM 04.04.22.04 DB 		Faber-Castell 2/82N Duplex
Made in Germany - 24 scales
Front Scale: T1 Cot, T2, L, A [ B, BI, CI, S' Cos', C ] D, S Cos, ST, P
Back Scale: LL03, LL02, LL01, K, DF [ CF, K', CIF, CI, C ] D, LL1, LL2, LL3
Multiple hairlines: 360, d, A, KW, PS


Faber-Castell 2/83 Log Log Duplex
ISRM 18.04.06.09 		Faber-Castell 2/83 Log Log Duplex
Made in Germany - 27 scales
Front Scale (extended)
K, T1 Cot1, T2 Cot2, DF [ CF, CIF, CI, C ] D, ST, S Cos, P
Back Scale (extended)
LL03, LL02, LL01, W2 [ W2', L, C, W1' ] W1, LL1, LL2, LL3
Multiple hairlines: 360, d, A, KW, PS
Gift of Leroy Hausler Collection


Faber-Castell 2/83 Log Log Duplex
ISRM 13.08.12.09.X

Insert (English) with Physical Properties of Metals.
Formulae for Mathematics, Mechanical, Civil and
Electrical Engineering, and Physics.
Hi resolution of the above - 600 dpi image 2.97 MB 		Faber-Castell 2/83 Log Log Duplex
Made in Germany - 27 scales
Front Scale (extended)
K, T1 Cot1, T2 Cot2, DF [ CF, CIF, CI, C ] D, S Cos, ST, P
Back Scale (extended)
LL03, LL02, LL01, W2 [ W2', L, C, W1' ] W1, LL1, LL2, LL3
Multiple hairlines: 360, d, A, KW, PS
Gift of Phillip Rodley, Upper Hutt, New Zealand

2/83, 62/83
Instructions
8.41MB PDF
Phillip Rodley
Plastic clamshell storage case 		Phil used this model of slide rule for one year at high school before calculators came in. He then spent 18 years working as a telephone linesman and later 18 years assembling and testing 11,000 volt circuit breakers. In his career he never needed to use a slide rule, but recently has begun enjoying relearning slide rules and logarithms. Phil is a contributor and donor of slide rules to ISRM. He is always on the hunt in New Zealand to find items to add to the ISRM galleries.


Faber-Castell 2/83N Novo-Duplex
ISRM 12.04.27.01 		Faber-Castell 2/83N Novo-Duplex
Made in Germany - 31 scales
Front Scale: T1, T2, K, A, DF [ CF, B, CIF, CI, C ] D, DI, S, ST, P
Back Scale: LL03, LL02, LL01, LL00, W2 [ W2', CI, L, C, W1' ] W1, D, LL0, LL1, LL2, LL3
Multiple hairlines: 360, d, A, KW, PSy
Donated By Rod Vance, Victoria, Australia
ISRM Exhibit Placard


Faber-Castell 2/84 Mathema
REF 		Faber-Castell 2/84 Mathema
Made in Germany - 22 scales
Front Scale: (exg), tan Xg, √X2-1, √X [ √x, 1/√x, 1/y, y ] Y, √(1-X2), sin Xg, (eX)
Back Scale: -0.1Ln X, -Ln X, -10Ln X [ tanh xg, 0.1 cosh xg, 0.1 sinhxg, sinh xg ] 10Ln X, Ln X, 0.1Ln X
Multiple hairlines
Archive - Rod Lovett Collection
Faber-Castell 2/84 Mathema Universal Slide Rule Instructions (English) 2.43MB. Courtesy of Gonzalo Martin, Spain - reglasdecalculo.com


Faber-Castell 2/84N Mathema Universal Slide Rule
ISRM 17.07.27.01
Faber-Castell 2/84N Mathema Universal Slide Rule
Made in Germany - ca 1971 - 24 scales
Front Scale: (exg), tan Xg, √X2-1, √X [ √x, 1/√x, 1/y, y ] Y, √(1-X2), sin Xg, (eX)
As in: L, T, √(x2-1), A [ B, BI, CI, C ] D, P, S, L
Back Scale:  10Ln X, Ln X, 0.1Ln X, Y [  y, 0.1cosh Xg, 0.1sinh Xg, sinhXg ] tanh Xg,  -0.1Ln X, -Ln X, -10Ln X
As in: LL0, LL1, LL2, A [B, 0.1 cosh, 0.1 sinh, sinh ] tanh, LL02, LL01, LL00
Multiple hairlines
Gift of Philip Rodley, Upper Hutt, New Zealand.
Instructions 4.1MB PDF


A.W. Faber 51/91
ISRM 12.02.19.04 		A.W. Faber 51/91
Made in Germany
Front Scale: A [ B, C ] D
Back Scale: [ sin/cos, lg, tg ]
Original Owner/Location: H.Stams (1942) Germany.
Previous Owner: William M. Day USAF (1947).
Donated by Nancy Day, Kansas City, Missouri

William M. Day 		William obtained this slide rule while in Germany during WWII. He was born on June 27, 1920 in Fort Dodge, Iowa. He volunteered for WWII than afterwards attended the State University of Iowa (now Univesity of Iowa) He majored in business and mathematics and graduated in 1949. He reurned to the Air Force and worked incommunications positions. He retired from military service as a Major in 1972. He worked an additional 10 years as a Credit Union Examiner for the State of Missouri. He lives in Kansas City, MO. Note: the case was repaired with match covers.


Faber-Castell 52/39/355 Basic
ISRM 20.02.09.02 		Faber-Castell 52/39/355 Basic
Made in Bavaria
Front Scale: A, [ B, C ] D
Back Blank: Adv: A. Buccellati, - Cairo & Alexandria
Cursor: Homemade out of sheets of plastic
Gift Of Ruth Stanier of Hereford, UK.


Faber-Castell 52/80 Mentor
REF S057 		Faber-Castell 52/80 Mentor
Made in Germany
Front Scale: A, Df [ CF, CIF, CI, C ] D, K
Back Scale: 25cm [ Instructions ] 10 inch
Multiple hairlines: 360, d-PS, KW, q
Original Owner/Location: NIB/Germany


Faber-Castell 52/81 Novo-Mentor (1970)
ISRM 14.10.09.04 		Faber-Castell 52/81 Novo-Mentor dc 9-70
Made in Germany
Front Scale: A, DF(K/Z) [ CF(T), CIF, CI(P%), C(T) ] D(Z), K
Back Scale: L, T1, T2, [ S', CI, C ] D, S, ST
Multiple hairlines: 360, d, PS, KW, q
Gift Of Edward Wright, Odenton, Maryland.


Faber-Castell 152-81
REF S166 		Faber-Castell 152-81
Made in Germany
Front Scale: A, DF [ CF, CIF, CI, C ] D, K
Back Scale: L, T1 Cot , T2 Cot, [ S' Cos, CI, C ] D, S Cos, ST
Multiple hairlines: 360, d, PS, KW, q
Original Owner/Location: Unk/Peru


Faber-Castell 52/82 Schul-D-Stab (early, no LL1 scale)
S167 		Faber-Castell 52/82 Schul-D-Stab (early, no LL1 scale)
Made in Germany . 21 Scales. T and S scale labels on top of each other.
Front Scale: L, K, A [ B, CI, C ] D, LL2, LL3
Back Scale: T1 Cot , T2 Cot, DF [ CF, CIF, C ] D, S Cos, ST
Multiple hairlines: 360, d, q, KW, PS
Original Owner/Location: Unk/Canada


Faber-Castell 52/82 Early (No DStsb model)
ISRM 18.04.06.140 		Faber-Castell 52/82 Early (No DStsb model)
Made in Germany - 22 scales. No 'DStab' Model name
Note: No CIF or P scale. T and S scale labels on top of each other.
Front Scale: L, K, A [ B, CI, C ] D, LL1, LL2, LL3
Back Scale: T1 Cot , T2 Cot, DF [ CF, CI, C ] D, S Cos, ST
Multiple hairlines: 360, d, A, V, KW, PS
Gift of Leroy Hausler Collection


Faber-Castell 52/82 Early (No DStab model) Swiss
ISRM 15.05.12.08 		Faber-Castell 52/82 Early (No DStab model) Swiss
Made in Switzerland - 22 scales. Narrow Cursor
Note: No CIF or P scale. T and S scale labels on top of each other.
Front Scale: L, K, A [ B, CI, C ] D, LL1, LL2, LL3
Back Scale: T1 Cot , T2 Cot, DF [ CF, CI, C ] D, S Cos, ST
Multiple hairlines: 360, d, A, V, KW, PS
Gift of Colin Barnes, UK


Faber-Castell 52/82 Schul-D-Stab
ISRM 09.01.12.57.X 		Faber-Castell 52/82 Schul-D-Stab
Made in Germany - 23 scales. date code 3A
Front Scale: L, K, A [ B, CI, C ] D, LL1, LL2, LL3
Back Scale: T1 Cot , T2 Cot, DF [ CF, CIF, CI, C ] D, S Cos, ST, P
Multiple hairlines: 360, d, A, V, KW, PS
Donated by David Hecht, Alexandria, VA


Faber-Castell 52/82 D-Stab Student Biplex
ISRM 14.10.09.09
 Faber-Castell 52/82 D-Stab Student Biplex
Made in Germany. 24 scales
Note additional CIF and P scale. T1 and S scales have labels side by side
Front Scale: L, K, A [ B, CI, C ] D, LL1, LL2. LL3
Back Scale: T1 Cot , T2 Cot, DF [ CF, CIF, CI, C ] D, S Cos, ST, P
Multiple hairlines: 360, d, A, V, KW, PS
Gift Of Edward Wright, Odenton, Maryland.

Instructions (11.7MB PDF)


Faber-Castell 52/82 D-Stab dc3
ISRM 15.05.12.07 		Faber-Castell 52/82 D-Stab dc3
Made in Switzerland. 24 scales.
Note additional CIF scale. T1 and S scales have labels side by side
Front Scale: L, K, A [ B, CI, C ] D, LL1, LL2. LL3
Back Scale: T1 Cot , T2 Cot, DF [ CF, CIF, CI, C ] D, S Cos, ST, P
Multiple hairlines: 360, d, A, V, KW, PS
Gift Of Colin Barnes, UK


Faber-Castell 52/82 (No Dstab, Scale Variant)
ISRM 17.05.02.02.X 		Faber-Castell 52/82 (No Dstab, Scale Variant)
Made in Switzerland - 24 scales. date code DP
Front Scale: L, K, A [ B, CI, C ] D, LL1, LL2, LL3
Back Scale: T1 Cot , T2 Cot, DF [ CF, CIF, CI, C ] D, S Cos, ST, P
Multiple hairlines: 360, d, A, V, KW, PS
Original owner: Black, UK scratched on slide
Gift of Mike Weaver, UK


Faber-Castell 152/82 Dstab Duplex
REF 		Faber-Castell 152/82 Dstab Duplex
Made in Germany - 24 scales.
Front Scale: L, K, A [ B, CI, C ] D, LL1, LL2, LL3
Back Scale: T1 Cot , T2 Cot, DF [ CF, CIF, CI, C ] D, S Cos, ST, P
Multiple hairlines: 360, d, A, V, KW, PS
Original owner: Black, UK scratched on slide
Archive Scan


A.W.Faber 55/91
REF S199 		A.W.Faber 55/91
Made in Germany
Front Scale: A [ B, C ] D
Back Scale:[ sin/cos, lg, tg ]
Back blank
Original Owner/Location: Unk/Germany


Faber-Castell 57/22 Business
ISRM 14.01.10.20 		Faber-Castell 57/22 Business
Made in Germany
Front Scale: 10inch // Conversions, DF(P/int) [ CF(Days), CI(R%), C(Days) ] D(int), L
Back Scale: [LL1, LL2, C]
Multiple hairlines:
Gift of Bill Wehrend Collection, Palo Alto, California.


Faber-Castell 57/86 Columbus
ISRM 09.01.12.58 		Faber-Castell 57/86 Columbus
Made in Germany - date code 573 (May 1973), 1962 copyright
Front Scale: 27 cm // A [ B, C ] D
Back: Instructions on basic math
Multiple hairlines: S, KW, HP
Donated by David Hecht, Alexandria, VA


Faber-Castell 57/87 Rietz (1957)
ISRM 09.01.12.59 		Faber-Castell 57/87 Reitz (1957)
Made in Germany - date code 157 (Jan 1957)
Front Scale: 27 cm // K, A [ B, CI, C ] D, L
Back Scale: [S, ST, T]
Multiple hairlines: S, KW, HP
Donated by David Hecht, Alexandria, VA


Faber-Castell 57/87 Rietz Schul-Rechenstab (1963)
ISRM 09.01.12.60 		Faber-Castell 57/87 Reitz Schul-Rechenstab (1963)
Made in Germany - date code 1163 (Nov 1963)
Front Scale: 27 cm // K, A [ B, CI, C ] D, L
Back Scale: [S Sin, ST, T Cot]
Multiple hairlines: S, KW, HP
Donated by David Hecht, Alexandria, VA


Faber-Castell 57/87 Rietz Schul-Rechenstab (1965)
ISRM 09.01.12.61 		Faber-Castell 57/87 Reitz Schul-Rechenstab (1965)
Made in Germany - date code 965 (Sep 1965)
Front Scale: 27 cm // K, A [ B, CI, C ] D, L
Back Scale: [S Sin, ST, T Cot]
Multiple hairlines: S, KW, HP
Donated by David Hecht, Alexandria, VA


Faber-Castell 57/87 Rietz (1966)
ISRM 15.05.12.21 		Faber-Castell 57/87 Rietz (1966)
Made in Germany dc466 (Apr 1966)
Front Scale: 10inch // K, A [ B, CI, C ] D, L
Back Scale: [S, ST, T]
Multiple hairlines: S, KW, HP
Gifted by Colin Barnes, UK


Faber-Castell 57/87 Rietz (Swiss 1973)
ISRM 15.05.12.05 		Faber-Castell 57/87 Reitz (Swiss 1973)
Made in Switzerland - date code 473 (Apr 1973)
Front Scale: 27 cm // K, A [ B, CI, C ] D, L
Back Scale: [S Sin, ST, T Cot]
Multiple hairlines: S, KW, HP
Gifted by Colin Barnes, UK


Faber-Castell 157/87 Rietz (inch scale) (1952)
ISRM 09.01.12.62 		Faber-Castell 157/87 Rietz
Made in Germany - date code 3A (1952), Injection Molded Geroplast
Front Scale: 10inch // K, A [ B, CI, C ] D, L
Back Scale: [S, ST, T]
Multiple hairlines: S, KW, HP
Original owner: Dick Cornelius
Donated by David Hecht, Alexandria, VA


Faber-Castell 157/87 Rietz (cm scale) (1971)
ISRM 13.06.20.08 		Faber-Castell 157/87 Rietz
Made in Germany - date code 271 (1971), Injection Molded Geroplast
Front Scale: 27cm // K, A [ B, CI, C ] D, L
Back Scale: [S, ST, T]
Multiple hairlines: S, KW, HP
Original owner: Located in New Zealand
Gift of Philip Rodley, Upper Hutt, NZ

43MB Pdf Instructions, Practice Diagram For Students


Faber-Castell 57/88
REF S005 		Faber-Castell 57/88 D-Stab
Made in Germany
Front Scale: 27cm, K, A [ B, L, CI, C ] D, S, ST, T1, T2
Multiple hairlines: S, KW, HP
Original Owner/Location: NIB/Germany


Faber-Castell 57/89 Log Log
ISRM 19.10.27.03 		Faber-Castell 57/89 Log Log
Made in Austria
Front Scale: 27 cm // K, A [ B, L, CI, C ] D, S Sin, ST, T1 Cot, T2 Cot
Back Scale: [ LL2, S' Cos, LL3 ]
Multiple hairlines: S, KW, HP
Gift of Jerome Drews of Kent, Washington.


Faber-Castell 57/89 Log Log (1973)
ISRM 15.05.12.21 		Faber-Castell 57/89 Log Log (1971)
Made in Austria - date code O71 (Oct 1971)
Front Scale: 27 cm // K, A [ B, L, CI, C ] D, S Sin, ST, T1 Cot, T2 Cot
Back Scale: [ LL2, S' Cos, LL3 ]
Multiple hairlines: S, KW, HP
Gifted by Colin Barnes, UK


Faber-Castell 61/87 System Rietz (1940)
ISRM 22.05.06.12 		Faber-Castell 61/87 System Rietz Elektro dc8-40 (August 1940)
Made in Birnbaum,Germany by A.W. Faber. Pocket version of 1/87
Material: Celluloid laminated Pearwood
Front Scale (extended): 14cm // K, A [ B, CI, C ] D, L || 1:25 Scale: Back Slide: [ sin, sin/tg, tg ]
Cursor: 3 hairlines: W, Hp, d,
Back: Conversions (German)
Gift Of Nancy Ulrich, Denver. Ted Ulrich Collection


Faber-Castell 319 Elektro (1932)
ISRM 22.05.06.13 		Faber-Castell 319 Elektro dc2-32 (January 1932)
Made in Birnbaum,Germany by A.W. Faber. Pocket version of 398
Material: Celluloid laminated Pearwood
Front Scale (extended): 5in // LL2, A(kw) [ B(hp), Temp°, C1, C ] D, LL3 || K
Back Slide: [ sin/cos, lg, tg ]
Well: Efficiency, Volt
Cursor: 3 hairlines: W, Hp, d, metal wrapped and divided with hairline for bottom 'K' Scale: Back: Conversions (German)
Gift Of Nancy Ulrich, Denver, Colorado. Ted Ulrich Collection.


Faber-Castell 61/98/319 Elektro (1938)
ISRM 20.04.01.259 		Faber-Castell 61/98/319 Elektro dc38-4 (April 1938)
Made in Birnbaum,Germany by A.W. Faber. Pocket version of 1/98/398
Material: Celluloid laminated Pearwood
Front Scale (extended): 5in // LL2, A(kw) [ B(hp), Temp°, C1, C ] D, LL3 || K
Back Slide: [ sin/cos, lg, tg ]
Well: Efficiency, Volt
Cursor: 3 hairlines: W, Hp, d, metal wrapped and divided with hairline for bottom 'K' Scale: Back: Conversions (German)
Gift of the Philip Stanley Collection.


Faber-Castell 62/82 Biplex
ISRM 12.06.24.03.X 		Faber-Castell 62/82 Biplex dcUnreadable
Made in Germany - 24 scales (early scale set)
Front Scale: 12.5cm, T1, T2, A [ B, BI, CI, C ] D, P, S, 5inch
Back Scale: LL03, LL02, LL01, K [ K', L, ST, CF ] DF, LL1, LL2, LL3
Multiple hairlines: 360, d, A, KW, PS
Original owner: David Herrera (written inside case)
Donated by Anonymous collector and daughter.
The collector, who prefers to remain anonymous, obtained a B.S. degree in Physics from Taiwan's National Tsing Hua University in 1971. His love for computation has encouraged him to build a collection of slide rules, HP and TI calculators, as well as abaci, many displayed at ISRM.


Faber-Castell 62/82 Biplex
REF P028 		Faber-Castell 62/82 Biplex
Made in Germany - 24 scales (Later scale set) with green tinted C & D scales
Front Scale: L, T1, T2, A [ B, BI, CI, C ] D, S Cos, ST, P
Back Scale: LL03, LL02, LL01, K [ K', C, CIF, CF ] DF, LL1, LL2, LL3
Multiple hairlines: 360, d, A, KW, PS
Original Owner/Location: NIB/Germany


Faber-Castell 62/83 Biplex
ISRM 20.04.01.056 		Faber-Castell 62/83 Biplex
Made in Germany - 24 scales
Front Scale: K, T1, T2, DF [ CF, CIF, CI, C ] D, ST, S Cos, P
Back Scale: LL03, LL02, LL01, W2 [ W2', L, C, W1' ] W1, LL1, LL2, LL3
Multiple hairlines: 360, d, A, KW, PS
Gift Of the Philip Stanley Collection


Faber-Castell 62/83N Novo-Duplex
REF 		Faber-Castell 62/83N Novo-Duplex
Made in Germany - 31 scales
Front Scale: T1, T2, K, A, DF [ CF, B, CIF, CI, C ] D, DI, S, ST, P
Back Scale: LL03, LL02, LL01, LL00, W2 [ W2', CI, L, C, W1' ] W1, D, LL0, LL1, LL2, LL3
Multiple hairlines: 360, d, A, KW, PS
Archive - Not in Collection


Faber-Castell 63/39 (1940)
ISRM 20.04.10.160 		Faber-Castell 63/39 dc40-12 (Dec 1940)
Made in Germany
Front Scale: 14cm // A [ B, C ] D
Back Scale: Blank
Back Adv: Knorr-Bremse Akt-Ges, Stahlwerk Volmarstein-Ruhr
Original Owner" Erich J. Schnider (on back of slide)
Gift Of the Philip Stanley Collection


Faber 163/81 Novo Mentor
ISRM 18.04.06.122.X 		Faber 163/81 Novo Mentor
Made in Germany - 17 scales
Front Scale: A, (K/Z)DF [ (T)CF, CIF, (P%)CI, (T)C ] (Z)D, K
Back Scale: L, T1, T2 [ S', CI, C ] D, S, ST
Multiple hairlines: 360, d, Theta, KW, PS
Gift of Leroy G. Hausler Collection


Faber-Castell 63/82 Biplex
ISRM 18.04.06.113 		Faber-Castell 63/82 Biplex
Made in Germany - 24 scales
Front Scale: L, T1, T2, A [ B, BI, CI, C ] D, S, ST, P
Back Scale: LL03, LL02, LL01, K [ K', C, CIF, CF ] DF, LL1, LL2, LL3
Multiple hairlines: 360, d, A, KW, PS
Gift of Leroy G. Hausler Collection


Faber-Castell 63/83 Novo-Biplex
ISRM 18.04.06.114 		Faber-Castell 63/83 Novo-Biplex
Made in Germany - 27 scales
Front Scale: K, T1, T2, DF [ CF, CIF, CI, C ] D, S, ST, P
Back Scale: LL03, LL02, LL01, W2 [ W2', L, C, W1' ] W1, LL1, LL2, LL3
Multiple hairlines: 360, d, q, KW, PS
Gift of Leroy G. Hausler Collection


Faber 63/87 (193?)
ISRM 20.04.01.015 		Faber 63/87 dc3?-1 (Jan, 193?)
Made in Germany.
Front Scale(Extended): 14cm // K, A [ B, CI, C ] D, L

Back scale: [ Sin, Sin/tg, Tg ]
Back: ARGUS Logo.
Gift of Philip Stanley Collection


Faber 63/91/338/S (1937)
ISRM 20.04.01.015 		Faber 63/91/338/S dc12/38 (Mar, 1937)
Made in Germany.
Front Scale(Extended): 5in // A [ B, C ] D

Back : [ S, L, T ]
Gift of Philip Stanley Collection


Faber 63/91 (1938)
ISRM 20.04.01.151 		Faber 63/91 dc12/38 (Dec, 1938)
Made in Germany for Gebrüder Theisen, Nürnberg. Fernruf 27401 Nurnberg
Front Scale: 14cm // a [ B, C ] D

Back : [ sin, lg, tg ]
Gift of Philip Stanley Collection


Faber-Castell 63/91R with Addiator (1944)
ISRM 20.03.01.55 		Faber-Castell 63/91R with Addiator (Feb.1944)
Made in Germany. Wood stock, celluloid laminate. Aluminum framed cursor No scale labels.
Front Scale: 14cm // A [ B, C ] D \\ 5.5cm
Back Scale: [ sin, lg, tg ] (must reverse slide to perform trig functions)
Back: 6-digit addiator.
Gift of Philip Stanley Collection


Faber 63/91/3385 (1937)
ISRM 20.04.01.015 		Faber 63/91/3385 dc12/38 (Mar, 1937)
Made in Germany.
Front Scale(Extended): 5in // A [ B, C ] D

Back : [ S, L, T ]
Gift of Philip Stanley Collection


Faber-Castell 63/98 Elektro with Addiator (1945)
ISRM 22.07.06.68 		Faber-Castell 63/98 Elektro with Addiator dc7-45 July, 1945
Made in Germany
Front Scale: 5.5in // LL2, A(KW) [ B(HP), Resistance circular yds/mils CI, C ] D, LL3
Back scale: [ Sin, Lg, Tg ]
Well scale: Dynamo/Motor n=%, Volt
Gift of Cindy Tate, Bozeman, Montana. Victor B. Tate Collection


Faber-Castell 63/98R Elektro with Addiator
REF P154 		Faber-Castell 63/98R Elektro with Addiator Hybrid
Made in Germany
Front Scale: 14cm // LL2, A(KW) [ B(PS), CI, C ] D, LL3 \\ 5.5in
Back scale: [ Sin, Lg, Tg ]
Well scale: Dynamo/Motor n=%, Volt
Original Owner/Location: M.Bachmann/Germany



Faber-Castell 66/91 (1937)
ISRM 20.04.10.137 		Faber-Castell 66/91 dc37-6 (Jun 1937)
Made in Germany
Note Railroad Track Scales. Missing Lens.
Front Scale (extended)
5in // A [ B, C ] D
Back scales; [ S, L, T ]
Back: Blank
Gift Of the Philip Stanley Collection


Faber-Castell 67-21 Reinforced Concrete (1959)
ISRM 20.04.10.424 		Faber-Castell 67-21 Reinforced Concrete
Made in Germany - dc759 (July 1959)
Front Scale (Extended)
14cm // L, K, A [ B, CI C ] D P, S Cos, T Cos
Back slide scale: [ B, X, h, O'b
Back: Nomograph, Che, Ce/db
Well Adv: La Casa del Ingeniero S.A., Lima -Peru
Gift Of the Philip Stanley Collection


Faber-Castell 67/22 Disponent (V1 slide)
ISRM 20.01.20.08 		Faber-Castell 67/22 Disponent dc355 (1955)
Made in Germany
Front Scale: 14cm // -50% 0 +100%, DF(KZ) [ CF(T), Val.(p%), E(T) ] V(Z.)
Back Scale: [Sh/d, £ ]
Gift of Dr. Michael Sachs of Elkins Park, Pennsylvania


Faber-Castell 67/22 Disponent (V2 slide)
ISRM 20.01.20.03 		Faber-Castell 67/22 Disponent dc1171 (1971)
Made in Germany
Front Scale: 14cm // -50% 0 +100%, DF(KZ) [ CF(T), CI(p%), C(T) ] D (Z.)
Back Scale: [Sh/d, £ ]
Gift of Dr. Michael Sachs of Elkins Park, Pennsylvania


Faber-Castell 67/22Rb Disponent with Addiator
ISRM 20.01.20.01.X 		Faber-Castell 67/22Rb Disponent with Addiator dc1161 (1961)
Made in Germany
Front Scale: 14cm // -50% 0 +100%, DF(KZ) [ CF(T), CI(p%), C(T) ] D (Z.)
Back Scale: [Sh/d, £ ]
Gift of Dr. Michael Sachs of Elkins Park, Pennsylvania


Faber-Castell 67/22Rb Disponent de bolsillo w/Addiator
ISRM 20.03.01.56 		Faber-Castell 67/22Rb Disponent de bolsillo w/Addiator dc964 (1964)
Made in Germany
Front Scale: 14cm // -50% 0 +100%, DF(Cap./Int) [ CF(Dias), CI(p%), C(Dias) ] D (Int.), Sh/d, £
Back Scale: [
Gift of Philip Stanley of Worchester, Massachusettes


Faber-Castell 67/39 Rietz - 14mm (1952)
ISRM 09.01.12.55 		Faber-Castell 67/39 Rietz - 14mm
Made in Germany - Date Code 52-10 (Oct 1952)
Front Scale: 14mm // A [ B, C ] D
Back: Blank
Well Advertisement: Linde
Donated by David Hecht, Alexandria, Virginia


Faber-Castell 67/39 Rietz - 5 inch (1956)
ISRM 20.04.01.297 		Faber-Castell 67/39 Rietz - 5 inch
Made in Germany - Date Code 56-2 (feb 1956)
Front Scale: 5in // A [ B, C ] D
Back: Blank
Gift Of Philip Stanley Collection


Faber-Castell 67/39 Rietz - 5in (1968)
ISRM 09.01.12.56 		Faber-Castell 67/39 Rietz - 5in
Made in Germany - Date Code 1168 (Nov 1968)
Front Scale: 5in // A [ B, C ] D
Back: Blank
Donated by David Hecht, Alexandria, Virginia
Instructions 6.78MB PDF


Faber-Castell 67/54 Darmstadt (1958)
ISRM 20.04.01.040 		Faber-Castell 67/54 Darmstadt dc51-8 (Aug 1958
Made in Germany
Front Scale (extended scale)
14cm, Lg // K, A [ B, CI, C ] D, P \\ S, T
Back Slide: [ LL1, Ll2, LL3 ]
Cursor: Multiple hairlines
Back: blank
Gift Of Philip Stanley Collection


Faber-Castell 67/54 B Darmstadt
ISRM 13.08.12.08 		Faber-Castell 67/54 B Darmstadt
Made in Germany
Front Scale (extended scale)
14cm // L, K, A [ B, CI, C ] D, P, S, T
Back Slide: [ LL1, Ll2, LL3 ]
Cursor: Multiple hairlines
Back: 5inch rule
Donated by Phillip Rodley, Upper Hutt, New Zealand


Faber-Castell 67/54 B Darmstadt
REF P029 		Faber-Castell 67/54 B Darmstadt
Made in Germany - Note: the K,A,B,C,D scales are gold color
Front Scale: 14cm // L, K, A [ B, CI, C ] D, P, S, T
Back Slide: [ LL1, Ll2, LL3 ]
Cursor: Multiple hairlines
Back: 5inch rule Adv: BASF
Original Owner/Location: Unk/England


Faber-Castell 67/54 RB Darmstadt/Addiator
ISRM 07.02.12.01
Faber-Castell 67/54 RB Darmstadt/Addiator
Made in Germany - Slide rule fron. addiator back
Front Scale: 14cm // L, K, A [ B, CI, C ] D, P, S, T
Back Slide: [ LL1, Ll2, LL3 ]
Cursor: Multiple hairlines
Note: The slide was found accessible by a puppy (see teeth marks)
Donation of Russell Fox, Anchorage, Alaska


Faber-Castell 67/87 Rietz (1965)
ISRM 09.01.12.54		 Faber-Castell 67/87 Rietz
Made in Germany - Date Code 865 (Aug 1965)
Front Scale: 14mm // K, A [ B, CI, C ] D, L
Back Scale: [S, ST, T]
Multiple hairlines
Back Advertisement: Barmag.
Donated by David Hecht, Alexandria, Virginia


Faber-Castell 67/87 Rietz
ISRM 13.06.28.03

Pocket Sleeve
Instructions 6.78MB PDF


Jim Rodgers

Faber-Castell 67/87 Rietz
Made in Germany - Date Code 765 (July 1965)
Front Scale: 5in // K, A [ B, CI, C ] D, L
Back slide: [S, ST, T]
Multiple hairlines
Gift Of Susan Jackson, Boulder, Colorado, daughter of Jim Rodgers
Jim Rodgers (1929-2012) used this slide rule (and others found within ISRM) during his career. He was a Naval Aviator and had training at the the Nuclear Weapons Training Center - Atlantic (c1968). He later resided in Boulder, Colorado. He was married to Ceil Rodgers for 63 years and had four children, Jim, Susan, Cathy and Stephen, and eight grandchildren. An avid reader, progressive thinker, political junkie, problem solver and perpetual optimist, Jim was loved and admired by everyone who knew him. Jim donated his body to science.


Faber-Castell 67/87b Rietz with Addiator
ISRM 22.03.01.54.X (Deaccessioned 08/23) 		Faber-Castell 67/87b Rietz with Addiator
Made in Germany - Date Code 53 (1953)
Front Scale: 14cm // K, A [ B, CI, C ] D, L \\ 5.5in
Back slide: { sin, sin/tg, tg ] (reverse slide to use trig functions)
Multiple hairlines
Back: 6-digit Addiator
Note: Stylus for addiator on side of rule.
Well Promo: La Casa del Ingeniero S.A. Lima. Distribuidores
Gift Of Philip Stanley


Faber-Castell 67/87b Rietz with Addiator
ISRM 13.10.07.06		 Faber-Castell 67/87b Rietz
Made in Germany - Date Code 865 (Aug 1965)
Front Scale: 5.5in // L, K, A [ B, CI, C ] D, S, ST, T
Back slide: blank
Multiple hairlines
Back Addiator
Note: Stylus for addiator kept in zippered hardcase.


Faber-Castell 167/87 Rietz (1936)
ISRM 20.04.10.108 		Faber-Castell 167/87 Rietz dc363 (Mar 1936)
Made in Germany
Front Scale (extended)
5in // A [ B, CI, C ] D, L
Back scales; [ S, ST, T ]
Back: Blank
Multiple Hairline cursor
Gift Of the Philip Stanley Collection


Faber-Castell 67/91 Rietz (1958)
ISRM 20.04.10.250 		Faber-Castell 67/91 Rietz dc258 (Feb 1958)
Made in Germany
Front Scale (extended): 14cm // A [ B, C ] D, L
Back scales; [ Sin, Lg, Tg ]
Back: Model number
Well Adv: Kugelfischer, GE GR. 1883
Multiple Hairline cursor
Gift Of the Philip Stanley Collection


Faber-Castell 67/98 Elektro (1957)
ISRM 20.04.10.95 		Faber-Castell 67/98 Elektro dc57-1 (Jan 1957)
Made in Germany
Front Scale(extended): 5in // LL2, A(Amp,KW) [ B(Yd,HP), CI, C ] D, LL3
Back Scale: [ Sin, Lg, Tg ]
Multiple hairlines
Gifted by the Philip Stanley Collection


Faber-Castell 67/98b Elektro (1951)
ISRM 20.04.10.162 		Faber-Castell 67/98 Elektro dc51-7 (Aug 1951)
Made in Germany
Front Scale(extended): 14cm // LL2, A [ B, CI, C ] D, LL3 \\ Dynamo/Motor%, Volt
Back Scale: [ Sin, Lg, Tg ]
Multiple hairlines
Gifted by the Philip Stanley Collection


Faber-Castell 167/98b Elektro
REF P159 		Faber-Castell 167/98b Elektro
Made in Germany
Front Scale: 14cm // LL2, A [ B, CI, C ] D, LL3, Dynamo/Motor%, Volt
Back Scale: [S, L, T] Multiple hairlines
Original Owner/Location: Unk/Germany


Faber-Castell 67/98Rb Elektro w/ Addiator (1956)
ISRM 20.03.01.53 		Faber-Castell 67/98Rb Elektro w/ Addiator dc6-56
Made in Germany
Front Scale(extended): 5in // LL2, A(Amp,KW) [ B(Yd,HP), CI, C ] D, LL3, Dynamo/Motor%, Volt
Back Scale: [ S, L, T ] (reverse to use)
Back: 6-digit Addiator Multiple hairlines
Original owner: R.W.J. (initials written on stock).
Gifted by the Philip Stanley Collection


Faber-Castell 73/39 10cm/4in (1936)
ISRM 20.04.10.279 		Faber-Castell 73/39 10cm/4in dc36-2 (Feb 1936)
Made in Germany
Front Scale (extended)
10cm // A [ B, C ] D
Back scales; [ blank ]
Back: Blank
Gift Of the Philip Stanley Collection


Faber-Castell 8/10 12.3cm dia
REF		 Faber-Castell 8/10 12.3cm Dia
Made in Germany
Front Scale: K, A, L, D ( C, CI, B, T1, T2, S, S )
Back: Instructions on Use
Multi-lined Cursor: KW, (3)PS, (2)q
Archive - Scan By Marc-Yvon Comeau Collection



Faber Castell 989 Complex Slide Rule Calculator
(Komplex-Rechenplatte)
ISRM 12.03.21.01.X 		Faber Castell 989 Complex Slide Rule Calculator (Komplex-Rechenplatte)
Made in Germany - This basically an integrated slide rule with 3 degrees of freedom and a nomograph.

Summary of Function By Dieter von Jezierski and Rodger Shepherd

Donated by Henry (Hank) Benoit, Kingston, Ontario, Canada

Henry Benoit (BSEE 1968, MSc 1970) had a hands-on biomedical engineering career in OB/GYN research at University of Toronto and clinical engineering at University of Ottawa Heart Institute. His graduate work focussed on electroanesthesia and electrosleep. During the 70s he applied an early Fairchild charge-coupled device to observation of internal organs and designed portable instrumentation based on the RCA COSMAC computer chip set and the FORTH language. Later he contributed to excimer laser applications in cardiac ablation surgery and integration of electronic technologies into clinical settings.
Hanks comment on this apparatus: "The 989 is a beautiful piece (to an engineer). My wife never saw it in that light. It was purchased for coursework in electromagnetic fields. It offered the contiuously-variable feature inherent in analog devices. Once the coursework was done I no longer found applications and electronic gadgets began to provide convenient complex functions anyway." See Hank's other personal slide rules, the Aristo 0970 Multilog and 870 (pocket) Multilog in the Aristo Gallery.

Instructions
German
6.07Mb PDF
Instructions
English
8.06Mb PDF
Alternate Translation By
Dieter von Jezierski
and Rodger Shepherd
English
7.08Mb PDF


REF Faber-Castell TR1 Electronic Calculator SR		 Faber-Castell TR1 Electronic Calculator SR Hybrid
Made in Germany
Front Electronic Calculator
+, -, /, *, %, 1/x, x2, M
Back Conventional Slide Rule
LL03, LL02, LL01, K, A [ B, BI, CI, C ] D, L, LL1, LL2, LL3
Multi-lined Cursor
Archive - Faber-Castell.de
Large Large
Scans of brochure donated by Dieter von Jezierski, Germany


REF Faber-Castell TR2
Electronic Calculator SR
ISRM 12.09.24.01

Faber-Castell.de
archive photo
 Faber-Castell TR2 Electronic Calculator SR Hybrid
Made in Germany - sn025120910
Front Electronic Calculator
+, -, /, *, X-Y, MS, MR, M1, M+, Pi, SQR, %, +/-, (, ), SinX, CosX, TanX. lnX, logX, etc
Back Conventional Slide Rule
Scale: LL03, LL02, LL01, K, A [ B, BI, CI, C ] D, L, LL1, LL2, LL3
Slide (reversible): [ T1 Cot, ST, S Cos, T, P, C ]
Multi-lined Cursor
Note: This scale set was only found on the TRs to compliment the calculator functions.


REF Faber-Castell TR3 Electronic Calculator SR		 Faber-Castell TR3 Electronic Calculator SR Hybrid
Made in Germany
Front Electronic Calculator
+, -, /, *, X-Y, MS, MR, M1, M+, SQR, %, +/-, (, ).
Back Conventional Slide Rule
LL03, LL02, LL01, K, A [ B, BI, CI, C ] D, L, LL1, LL2, LL3
Multi-lined Cursor
Archive - Faber-Castell.de


Instructions (German & English) 2.66MB
Faber-Castell Verlag Chemie (Chemical slide rule)
ISRM 12.09.15.01.X 		Faber-Castell Verlag Chemie (Chemical slide rule)
Made in Germany by Faber-Castell for Verlag Chemie - Weinheim
Front Scales
K, T1 Cot, T2 Cot, DF [ CF, L, CI, C ] D, LL3, LL03, LL02
Back Scales
C, OCH3, N(Si/2) O(S/2), F Br, H MG [ B %, 1) CI C ] D, B, P, Cl J
Multi-lined Cursor
Instructions courtesy of Gonzalo Martin, Spain - reglasdecalculo.com

A.W. Faber Refrigerant Vapor Pressure Convertor
ISRM 18.07.11.06		 A.W. Faber Refrigerant Vapor Pressure Convertor
Made in Germany by Faber-Castell for Bitzler Kuhlmaschinenbau GMBH, Sindelfingen
Front Scales: °Fahr, F22 kg/cm2 atü PSI G, F12 kg/cm2 atü PSI G, CH3CL kg/cm2 atü PSI G, °Cels
Back Scale: Zoll Inches, m/m
Note: F22, F12 and CH3CL are types of refrigerant.
Gifted by Phil Stanley of Worcster, Massachussettes
Philip Stanley retired from engineering to become a full-time dealer in and appraiser of antique scientific instruments and tools as The Analytical Engine. He has written two books on antique measuring instruments, and numerous articles on instruments and technology, and has given several talks on these subjects. Phil appeared on the Antiques Road Show on PBS, as an appraiser, in 2012, 2013, 2014.


A.W. Faber Turning Speed Calculator
ISRM 20.04.01.359		 A.W. Faber Turning Speed Calculator
Made in Germany by Faber-Castell for National Acme Co. USA
Front Scales: Spindle Revs per Minute [ Feed, Length of Cut ] Time Taken in Seconds, Time Taken in Minutes
Back Table: Stock sizes, Cutting Speeds
Gifted by Phil Stanley of Worcster, Massachussettes


Faber-Castell Scaling Slide Rule For Organ Pipes (1986)
ISRM 18.12.08.04		 Faber-Castell Scaling Slide Rule For Organ Pipes - System Rennsch
Rechenschieber Fü Orgelpfeifen - System Rennsch
Made in W. Germany by Faber-Castell for Orgelbau-Fachverlag
Front Scales: 1:Mensur Scale (Decreasing), 2:Transposition of Wooden Pipes, 3;T °F °C, [ 4:Du, 5:AL, 6:Mk/EC, 7:U ] 8:CIF, 9:Mensur Scale (Increasing)
Back Scale:.38.5cm, Tables of Pipe Lengths and Diameters, Theoretical Lengths of Open Cylindrical Labial Pipes
Gift of Phillip Rodley, Upper Hutt, New Zealand. This belonged to his brother, George Deans, a Pipe Organ Builder in NZ.
ISRM dating guide

1966 Catalog and pages on scales of slide rule models and construction description.and Peter Hollands Rechenschieber A.W. Faber-Castell Slide Rules (2020 edition)
Copyright © 2003-
International Slide Rule Museum
